Steel Frame Construction Factory Earthquake And Wind Resistant CE ISO SGS Certified

Name: Steel Frame Construction Factory Earthquake And Wind Resistant CE ISO SGS Certified
Brand: HCGG
Price: 20 USD

Quality Steel Frame Construction Factory Earthquake And Wind Resistant CE ISO SGS Certified wholesale

Project Solution Capability : CAD graphic design, 3D Tekla modeling design, total solution for projects,One-stop steel structure solution,Project-based supply

Roof and Wall panel : EPS/Rock wool/PU / PIR sandwich panel,Corrugated/Trapezoidal steel sheet/Customized

Payment Terms : L/C,T/T,Western Union,.pay

Main Structurel Material : Q355B/ASTM A572 Gr.50/EN S355/JIS SM490

Brand Name : HCGG

MOQ : 100 square meters

Model Number : SSF001

After-sale Service : Online Technical Support, Onsite Installation,Onsite Training,Onsite Inspection,Installation Drawings Support

Column and Beam : Welded H-section/Hot-rolled H-beam/Box column

Price : USD20-70Square Meter/Negotiable

Life Span : More Than 50 Years

Certification : CE/ISO 9001/ISO 3834/ISO 14001/ISO 45001

Service Life Time : 50+ Years

Supply Ability : 50000 Tons/year

Delivery Time : 20-40days

Service Life : 20-50 Years

Surface treatment : Hot-dip galvanized Zinc-rich primer + top coat Anti-corrosion coating

Secondary Structurel Material : Q235B / ASTM A36/ EN S235JR / JIS SS400

Seismic and Wind Resistance Rating : Designed according to local seismic codes/Wind：0.3-1.1 KN/㎡/81-150 mph

Place of Origin : Henan,China

Customization : Style / Size (Span, Height, Length) /Color / Material / Crane Capacity

Purlin : C.Z Shape Steel Channel

Window : Aluminum alloy / PVC /Industrial louver window

Door : Sliding/Rolling shutter/Hinged steel/Customized steel door

Other Material : Q460 / ASTM A572 Gr.65 /EN S460 / JIS SM570

Contact Now

Heavy Steel Structure Factory Buildings

CE, ISO, and SGS certified manufacturer offering direct sales of earthquake and wind resistant steel frame construction factories.

What is a Steel Structure Factory?

A steel structure factory (also called a pre-engineered steel building/PEB factory) is a modern industrial building where structural steel serves as the primary load-bearing framework, instead of traditional reinforced concrete. Its components are mostly prefabricated in a dedicated fabrication plant with high precision, then transported to the site for fast bolted/welded assembly.

Core Components

Main Frame: Steel columns, main beams/rafters (often H-sections), forming the core skeleton to bear all vertical and lateral loads
Secondary Frame: Purlins (C/Z-shaped steel), bracings, tie rods—boosting rigidity and wind/seismic resistance
Envelope System: Insulated sandwich panels, corrugated steel sheets for roofs and walls, providing weatherproofing, thermal insulation, and noise reduction
Accessories: Crane beams, doors, windows, ventilation systems, fireproof coatings, anti-corrosion treatments (e.g., galvanizing)

Product Specifications

Component	Specification
Main Material	Q235-Q355B Welded H Section Steel or Hot Rolled H Section Steel
Surface Treatment	Painted or Galvanized
Main Frame - Column	Q235, Q355 welded H section steel
Main Frame - Beam	Q235, Q355 welded H section steel
Secondary Frame - Purlin	Q235 Z/C steel purlin
Secondary Frame - Knee Brace	Q235 angle steel
Secondary Frame - Tie Rod	Q235 circular steel pipe
Secondary Frame - Brace	Q235 round bar
Vertical & Horizontal Support	Q234 angle steel/round bar/circular steel pipe
Roof & Wall Panel	EPS Sandwich Board, Single Corrugated Steel Plate, Glass Cotton Colored Board for Customer Choice
Window	PVC or Aluminum Alloy
Door	Sliding Door or Rolling Shutter Door

Our Services

Design: We provide free design services tailored to your requirements
Manufacturing: Over 20 years of experience in steel structure manufacturing with proven capability for diverse projects
Installation: Detailed drawings provided for smooth installation, plus installation supervision and training services with on-site or online engineering support

Steel Frame Construction Factory Earthquake And Wind Resistant CE ISO SGS Certified

Our Advantages

Direct Export Manufacturer: Integrated design, manufacturing, and export with competitive factory-direct pricing
Custom Design Capability: Customized non-standard and project-based steel structures according to drawings and technical requirements
Precision Manufacturing: Strict quality control from material selection to coating, ensuring international standard compliance
Safe Delivery: Comprehensive production management ensuring project stability and timely delivery
Lifetime Support: Professional after-sales service team offering remote or on-site technical support with full quality responsibility
Expert Consultation: Professional technical experts provide one-on-one consulting to understand needs and optimize solutions

Steel Frame Construction Factory Earthquake And Wind Resistant CE ISO SGS Certified
